© 2010 Baja, Inc. All Rights Reserved. 31 — English
DIMENSIONS AND DRY MASS:
Overall length ......................................64.17 in. (1630 mm)
Overall width ........................................41.31 in. (1050 mm)
Overall height ........................................36.22 in. (920 mm)
Wheelbase........................................... 43.31 in. (1100 mm)
Ground clearance ....................................3.94 in. (100 mm)
Seat height ............................................29.92 in. (760 mm)
Dry weight.............................................. 330.7 lbs. (150 kg)
ENGINE:
Type ................................................. Four stroke, air cooled
Number of cylinders........................................................... 1
Bore and stroke ................................... 57.4 mm x 57.8 mm
Displacement ..........................................................149.5 cc
Compression ratio ....................................................... 8:5:1
Carburetor ................................................................. PZ-19
Air cleaner ............................... Polyurethane foam element
Max power ................................ 7,500-8,000 r/min. (4.0kW)
Rated power ........................................7,000 r/min. (6.0kW)
Rated torque ...................................... 5,500 r/min. (9.0 Nm)
TRANSMISSION:
Primary reduction ....................................................... 4.095
Final reduction ............................................................ 2.652
Chain driven
PRODUCT SPECIFICATIONS
ELECTRICAL:
Ignition type ...................................................................CDI
Generator system .......................................... A.C. Magneto
Battery type, voltage, capacity........................... 12V, 6.5AH
Headlight ....................................................12V, 18/18w x 2
Spark plug ............................................................... A7RTC
CAPACITIES:
Engine lubricant ......................... 0.95 qt. (0.9 l) SAE15W40
Fuel tank ....................................................... 1.583 gal. (6 l)
BRAKES:
Brake type .......................................................... Drum front
Disc rear
SUSPENSION:
Front ........................................................... 2 spring shocks
Rear ..............................................................1 spring shock
Front suspension travel .............................1.97 in. (50 mm)
Rear suspension travel ................................2.2 in. (56 mm)
TIRES:
Front ...................................................................AT19 x 7-8
Rear .................................................................AT18 x 9.5-8
FRAME:
Frame type ..........................................................Steel tube
Caster angle .............................................................. 4 deg.
WARNING:
This product contains chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm.
CALIFORNIA PROPOSITION 65
