Chapter 10 : RS-232 PROGRAMMER'S GUIDE (continued)
STUDIO SCAN XTD825 / 625™
PAGE 22
10-4. COMMANDS AND RESPONSES TABLE (continued)
ASCII
RESPONSE
COMMAND
TYPE
VALUE
COMMAND
DESCRIPTION
MIN MAX
DESCRIPTION
STATUS COMMANDS
U
UNIT
Measures unity in kHz.
Rd
0 65535
il
ILD
This command allows to calculate the
input line frequency in kHz
Rd
0 65535 Line frequency (in kHz) = (UNIT VALUE)
÷
(ILD VALUE).
id
IFD
This command allows to calculate the
input frame frequency in Hz.
Rd
0
65535 Frame frequency (in Hz) = (Line frequency in
Hz)
÷ (IFD VALUE).
ik
IST
Input sync type detection
Rd
0
3
0 = separate H & V
1 = Composite sync (TTL)
2 = SOG (Sync On Green)
3 = Composite sync (analog)
ip
IPS
Input sync detection.
Rd
0
1
0 = no sync detected 1 = sync detected
ih
IHP
Sign of the horizontal input sync.
Rd
0
1
0 = negative
1 = positive
iv
IVP
Sign of the vertical input sync.
Rd
0
1
0 = negative
1 = positive
ii
IIN
Interlaced signal detection.
Rd
0
1
0 = not interlaced
1 = interlaced
io
IOO
Status of the signal in comparison with
the input range frequency.
Rd
0
1
0 = in range
1 = out of range
if IFA
Input
format detection
Rd
0
8
0 = no signal
1 = "out of range" signal.
2 = VGA1 350l
3 = VGA2 400l
4 = VGA3 480l
5 = SVGA
6 = XGA
7 = SXGA
8 = UXGA
GA
REFA
Status of the synchronization mode
Rd
0 2
0
=
internal
1 = genlock
2 = wrong signal.
GF
REFF
Status of the synchronized format
(genlock).
Rd
0
2
0 = no signal
1 = NTSC 59.94 Hz.
2 = PAL 50 Hz.
GT
REFT
Frame frequency of the synchronized
signal (genlock) (in hundredth of Hz)
Rd
0 65535
NOTE: * = available with the optional DVI input only.
Rd = Read only command.
Rd/Wr = Read and write command.
