Chapter 8 : TECHNICAL SPECIFICATIONS (continued)
STUDIO SCAN XTD825 / 625™
PAGE 16
8-3. GENLOCK (INPUT / OUTPUT)
Black Burst:
PAL or NTSC (Loop through).
Impedance:
75 Ohm or Hi-Z.
8-4. REMOTE PORT
Level:
RS-232.
Data Rate:
9600 bauds, 8 bits data, 1 bit stop, no parity bit, no flow control.
8-5. ENVIRONMENTAL
Power Supply:
Internal CE / UL / CSA / IEC 950 (50W).
Input: 100VAC to 250VAC; 50-60Hz; I = 1A Max.
Storage temperature:
- 25 °C to + 85 °C (- 13°F to + 185°F).
Operating temperature:
0°C to 50°C (32°F to + 122°F).
Maximum ambient operating temperature: < 40 °C.
Hygrometry:
10 % to 80 % (without condensation).
Dimensions:
• XTD825: W 440 x D 300 x H 44 mm / 17.3” W x 11.8” D x 1.74” H.
W = 482mm / 19" with the rackmount kit.
• XTD625: W 482 x D 300 x H 44 mm / 19” W x 11.8” D x 1.74” H.
• Compatible with 19" Standard, height = 1 unit.
Weight:
3.3 kg / 7.3 Lbs.
