Chapter 5 : LCD FUNCTIONS DESCRIPTION (continued)
STUDIO SCAN XTD825 / 625™
PAGE 12
3
[IMAGE MENU] + ENTER.
3-1
[flicker filter] + ENTER.
Select one of the 8 levels of the anti-flicker with and validate with ENTER.
3-2
[Black Level] + ENTER. (Not available for the DVI input source).
Adjust the Black level with + ENTER.
3-3
[RGB Levels] + ENTER. (Not available for the DVI input source).
Select an item with + ENTER.
• [Red] = Adjust the level of the Red with + ENTER.
• [Green] = Adjust the level of the Green with + ENTER.
• [Blue] = Adjust the level of the Blue with + ENTER.
3-4
[under/over] + ENTER.
Select an item with + ENTER.
• [underscan] = the output image is full screen.
• [overscan] = the output is 10% bigger than in underscan mode.
3-5
[H. smooth] + ENTER. (Not available for the DVI input source).
Select an item with + ENTER.
• [ON] = active the horizontal filter.
• [OFF] = inactive the horizontal filter.
3-6
[position status] + ENTER.
Displays the image position status.
3-7
[zoom status] + ENTER.
Displays the image zoom status.
3-8
[preset] + ENTER.
This function allows to set all the image parameters (flicker filter, Black level, RGB level, under/overscan, position
& size) to the factory settings.
4
[CONTROL MENU] + ENTER.
4-1
[panel locking] + ENTER.
This function allows to lock the front panel buttons. Select an item with + ENTER.
• [lock] = allows to lock the front panel push button.
• [unlock] = doesn't lock the front panel button.
NOTE: To unlock push simultaneously on ENTER and EXIT.
4-2
[version] + ENTER.
Status of the internal firmware.
4-3
[erase memories] + ENTER.
This function allows to erase all the image settings memorized.
4-4
[default value] + ENTER.
This function allows to clear the following adjustments and set them to the factory value:
FUNCTION
POSITION
FUNCTION
POSITION
1-2 Input type
analog
2-4 RGB/YUV out
YUV
1-3 Genlock H Ph
0
2-5 test pattern
no.
1-4 Genlock Sc. Ph.
0
3-1 Flicker Filter
level 1.
1-5 SOG input
no.
3-2 Black level.
0
1-6 H sync load
Hi-Z.
3-3 RGB levels.
0
1-7 Genlock load
Hi-Z.
3-4 under/over
underscan.
2-2 Output standard
NTSC
3-5 H smooth
off.
2-3 Output rate
internal.
4-1 panel locking
unlock.
