STUDIO SCAN XTD825 / 625™
PAGE 14
Chapter 7 : UPDATING THE STUDIO SCAN XTD825 / 625 ™
The STUDIO SCAN XTD825 / 625 ™ can be update thanks a COMPUTER (PC) via its REMOTE CONTROL (RS-232)
connector.
7-1. CONNECTIONS:
c Connect the "REMOTE CONTROL RS-232" connector of the STUDIO SCAN XTD825 / 625 ™ to the SERIAL port
of your COMPUTER with a DB9 M/F straight cable.
d Connect the STUDIO SCAN XTD825 / 625 ™ to an AC power outlet.
e Switch OFF the STUDIO SCAN XTD825 / 625 ™ (FRONT PANEL SWITCH = O).
7-2. UPDATE INSTRUCTIONS:
c Open the file "Updater825 " (in start/Program/ANALOG WAY/XTD825).
d Click on "START" on the SOFTWARE.
e Press the ENTER button of the STUDIO SCAN XTD825 / 625 ™ (FRONT PANEL), and SWITCH it ON
simultaneously (FRONT PANEL SWITCH = I ). All front panel LEDs switch ON and OFF, the LCD screen
displays Downloading, and the upgrade will start. Then you can release the ENTER button.
f When the software displays "Program operation completed", SWITCH OFF and ON the STUDIO SCAN XTD825 /
625 ™ with the FRONT PANEL SWITCH.
g Click on the "Quit" button to close the update SOFTWARE.
NOTE: YOUR STUDIO SCAN XTD825 / 625 ™ IS NOW READY TO WORK.
NOTE: THE UPDATER FILES ARE AVAILABLE ON OUR WEB SITE: www.analogway.com
