Chapter 8 : TECHNICAL SPECIFICATIONS
8-1. COMPUTER INPUT
• ANALOG COMPUTER INPUT (on HD15 connector)
Line frequency: XTD825: From 29 kHz to 110 kHz.
XTD625: From 29 kHz to 85 kHz.
Frame frequency: Up to 130 Hz.
Resolution: XTD825: Up to 1600 x 1200.
XTD625: Up to 1280 x 1024.
Sync. types: RGBHV, RGB/S, RGsB (Sync On Green).
Levels: R, G, B = 3 x 0.7 Vp/p.
H & V Sync = TTL.
Composite Sync = TTL and 0.3 V.
SOG (Sync On Green) = 0.3 V.
Impedance: R, G, B, V, H = 75 Ohm.
• DIGITAL COMPUTER INPUT (on optional DVI-I connector)
Format: Digital Visual Interface (DVI)
Resolution: • 640 x 480 @ 60Hz (up to 120 Hz).
• 800 x 600 @ 60Hz (up to 120 Hz).
• 1024 x 768 @ 60Hz (up to 120 Hz).
• 1280 x 1024 @ 60Hz (up to 75 Hz).
• 1600 x 1200 @ 60Hz BR (reduced blanking).
8-2. VIDEO OUTPUTS
• RGB/S VIDEO (on 4 BNC connectors).
Frequency: 15.625 kHz / 50 Hz (625 lines).
15.735 kHz / 60 Hz (525 lines).
Levels: R, G, B = 0.7 Vp/p.
Sync = 2 Vp/p.
SOG = 2 Vp/p.
Impedance: 75 Ohm.
• COMPONENT (on 3 BNC connectors).
Frequency: 15.625 kHz / 50 Hz (625 lines).
15.735 kHz / 60 Hz (525 lines).
Levels: Y = 1 Vp/p (0.7 V Luma + 0.3 V Sync.).
R-Y, B-Y = 0.7 Vp/p.
Impedance: 75 Ohm.
• S.VIDEO (on 4-pin mini DIN connector).
Standard: PAL: 15.625 kHz / 50 Hz - 625 lines.
NTSC: 15.735 kHz / 60 Hz - 525 lines.
Levels: Y = 1 Vp/p (0.7 V Luma + 0.3 V Sync.).
C = 0.3 Vp/p (Chroma Burst).
Impedance: 75 Ohm.
• COMPOSITE VIDEO (on BNC connector or HD15 female connector).
Standard: PAL: 15.625 kHz / 50 Hz - 625 lines.
NTSC: 15.735 kHz / 60 Hz - 525 lines.
Level: 1 Vp/p (0.7 V Luma + 0.3 V Sync.).
Impedance: 75 Ohm.
• SDI OUTPUT (OPTIONAL) (on BNC)
Signal: 270 Mbps serial digital output conforming to SMPTE 259M.
Impedance: 75 Ohm.
