158
Programmation : Programmer les contours
6.3 Appr
oc
he et sor
tie du cont
our
Exemple de séquences CN
N50 G00 G40 G90 X-30 Y+50 *
Point de départ
N60 G01 G41 X+0 Y+50 F350 *
Premier point du contour
N70 G26 R5 *
Approche tangentielle de rayon R = 5 mm
. . .
PROGRAMMER LES ÉLÉMENTS DU CONTOUR
. . .
Dernier point du contour
N210 G27 R5 *
Sortie tangentielle avec rayon R = 5 mm
N220 G00 G40 X-30 Y+50 *
Point final
