Thermor Riva 2 Manuel d'utilisation
Page 18
16
2-3) Turbo mode
It is the mode enabling to set the device into Forced Operation, ensuring prompt temperature
increase in the room over the time defined (maximum power for conventional models and fan activation
point for models with ventilating fan).
a) Leave the switch
on the Marche position.
b) Select the time for the Turbo using the knob
.
c) Press the command
, the indicators
and
light.
d) The TURBO mode can be interrupted manually before the end of the time set. In order to do
this, press the command
again.
NB: For piloted devices, only the heating stop and frost setting instructions are prioritised when
TURBO mode is activated (the other instructions are inoperative).
3) Use on central heating for versions mixed with fan in WINTER position.
a) Place the switch
on the ON position, the indicator
lights up.
b) Place the temperature knob
on frost-free.
Turbo mode (
see paragraph 2-3)
Repeat elements a) to d).
NB:The temperature adjustment of the device is made using the tap C (thermostatic or not).
4) Locking commands
It is possible to lock the knob
or restrict its use, preventing untimely handling of the device (chil-
dren…).
1- Locking the knob:
a) Set the knob to the position required.
b) Using a small-size flat-blade screwdriver, pull the knob’s cap (1).
c) Detach pin P from its stand using a cutting tool.
d) Set pin P in the alignment of arrow B (2).
e) Refit the cap.
2- Limitation of the knob’s use range:
a) Using a small-size flat-blade screwdriver, pull the knob’s cap (1).
b) Remove the two P pins from their stand using a cutting tool.
c) Position the two P pins at each end of the operating range desired (3).
d) Refit the cap.
B
2
3
P
P
1
