15
1) Description of the control panel
2) Use on electricity for versions:
- All electric with or without fan.
- Mixed with fan in SUMMER position.
2-1) Setting the CONFORT temperature
It is the temperature desired when the room is occupied.
a) Set the switch to to the ON position, the indicator lights.
b) Align the toothed screw with the marking : the indicator light illuminates if the tempe-
rature is less than desired.
Wait a few hours for the temperature to stabilise.
If the temperature setting does not suit you, adjust it using the adjusting screw . Proceed step-
by-step using the notches (one notch at a time).
The thermostat’s cycle takes several minutes. It is possible that the heating indicator may not react
instantaneously, but instead only on the next thermostat cycle.
2-2) Standby (Hors Gel) Mode
It is the mode enabling to maintain a temperature of approximately 7°C in the room in case of pro-
longed absence from the house.
a) Leave switch on the Marche position.
b) Set the knob to .
WARNING
Using the bleeder, make sure that the device is correctly filled. If, when you open the
bleeder, the water does not flow regularly, please contact your fitter.
It is forbidden to leave A switch on l when the supply tap C is open.This abnormal use
causes cancellation of the warranty.
The use of this device without water would lead to the definitive deterioration of the
resistor.This incident would definitely require its replacement, which is not covered by
the Maker's guarantee.
The boiler return tap D must obligatorily remain open, even in the case of the SUMMER
SETTING in order to allow expansion of the fluid in the circuit so as to avoid any damage
to the device.
USE OF THE CONTROL BOX
Temperature setting knob with Hors Gel
position and ability to restrict the range.
Time adjustment knob TURBO 1/4h, 1/2h,
1h, 2h.
Power On indicator
TURBO indicator
TURBO control
Heating ON/OFF switch
Heating indicator
GB
