12
320 mm
mini
200 200 200 200
A
B
1
4 5
3
525 mm
mini
A
B
Note: The pins supplied with the device are of the standard type. In case of a particular stand, use
appropriate pins.
Traditional model
without fan
Traditional model with fan
Curved model with and
without fan
TRADITIONAL AND CURVED
MODELS
TRADITIONAL AND CURVED
MODELS WITH FAN
MODEL WITH FAN
Power (W) 500 750 1000
500
+1000
750
+1000
1000
+1000
500
+1000
750
+1000
1000
+1000
Measurement (A)
for fitting lugs (mm)
656 1066 1599 451 861 1394 451 861 1394
Measurement (B)
for fitting lugs (mm)
400 386 386
2 1’
6
