DGC-2020HD Table des registres hérités
Registre Description Type Unités
Facteur
d'échelle
L/E Plage
VAB alternateur = 7
VBC alternateur = 8
VCA alternateur = 9
Vmoy LL alternateur = 10
VAN alternateur = 11
VBN alternateur = 12
VCN alternateur = 13
Vmoy LN alternateur = 14
Hz BUS 1 = 15
Vab BUS 1 = 16
Vbc BUS 1 = 17
Vca BUS 1 = 18
Vmoy LL bus 1 = 19
VA bus 1 = 20
VB bus 1 = 21
VC bus 1 = 22
Vmoy LN bus 1 = 23
Hz bus 2 = 24
VAB bus 2 = 25
VBC bus 2 = 26
VCA bus 2 = 27
Vmoy LL bus 2 = 28
VAN bus 2 = 29
VBN bus 2 = 30
VCN bus 2 = 31
Vmoy LN bus 2 = 32
PF alternateur = 33
PF BUS 1 = 34
PF BUS 2 = 35
kWH pos. alternateur = 36
kWH nég. alternateur = 37
kWH pos. bus 1 = 38
kWH nég. bus 1 = 39
kWH pos. = 40
kWH nég. bus 2 = 41
IA alternateur = 42
IB alternateur = 43
IC alternateur = 44
I Moy alternateur = 45
IA BUS 1 = 46
IB BUS 1 = 47
IC BUS 1 = 48
Imoy bus 1 = 49
IAN bus 2 = 50
IBN bus 2 = 51
ICN bus 2 = 52
Imoy bus 2 = 53
IG=54
I AUX = 55
kW A alternateur = 56
kW B alternateur = 57
kW C alternateur = 58
kW TOT. alternateur = 59
kW A BUS 1 = 60
kW B BUS 1 = 61
kW C BUS 1 = 62
kW TOT. BUS 1 = 63
kW A BUS 2 = 64
kW B BUS 2 = 65
kW C BUS 2 = 66
kW TOT. BUS 2 = 67
kVA A alternateur = 68
kVA B alternateur = 69
kVA C alternateur = 70
kVA TOT. alternateur=71
kVA A BUS 1 = 72
kVA B BUS 1 = 73
kVA C BUS 1 = 74
kVA TOT. BUS 1 = 75
kVA A BUS 2 = 76
kVA B BUS 2 = 77
kVA C BUS 2 = 78
kVA TOT. BUS 2 = 79
kvar A alternateur = 80
kvar B alternateur = 81
kvar C alternateur = 82
kvar TOT. alternateur = 83
kvar A BUS 1 = 84
kvar B BUS 1 = 85
kvar C BUS 1 = 86
kvar TOT BUS 1 = 87
