9469370991 Rev A 335
DGC-2020HD Table des registres hérités
Registre Description Type Unités
Facteur
d'échelle
L/E Plage
45572-73 Bits de pré-alarme de protection
configurable Uint32 s/o s/o L Bit 0 = Protection configurable 8 Minimum
2
Bit 1 = Protection configurable 8 Minimum
1
Bit 2 = Protection configurable 8 Maximum
2
Bit 3 = Protection configurable 8 Maximum
1
Bit 4 = Protection configurable 7 Minimum
2
Bit 5 = Protection configurable 7 Minimum
1
Bit 6 = Protection configurable 7 Maximum
2
Bit 7 = Protection configurable 7 Maximum
1
Bit 8 = Protection configurable 6 Minimum
2
Bit 9 = Protection configurable 6 Minimum
1
Bit 10 = Protection configurable 6
Maximum 2
Bit 11 = Protection configurable 6
Maximum 1
Bit 12 = Protection configurable 5 Minimum
2
Bit 13 = Protection configurable 5 Minimum
1
Bit 14 = Protection configurable 5
Maximum 2
Bit 15 = Protection configurable 5
Maximum 1
Bit 16 = Protection configurable 4 Minimum
2
Bit 17 = Protection configurable 4 Minimum
1
Bit 18 = Protection configurable 4
Maximum 2
Bit 19 = Protection configurable 4
Maximum 1
Bit 20 = Protection configurable 3 Minimum
2
Bit 21 = Protection configurable 3 Minimum
1
Bit 22 = Protection configurable 3
Maximum 2
Bit 23 = Protection configurable 3
Maximum 1
Bit 24 = Protection configurable 2 Minimum
2
Bit 25 = Protection configurable 2 Minimum
1
Bit 26 = Protection configurable 2
Maximum 2
Bit 27 = Protection configurable 2
Maximum 1
Bit 28 = Protection configurable 1 Minimum
2
Bit 29 = Protection configurable 1 Minimum
1
Bit 30 = Protection configurable 1
Maximum 2
Bit 31 = Protection configurable 1
Maximum 1
45574 Kvar alternateur A Int32 kvar s/o L (-2 147 483 648) - 2 147 483 647
45576 Kvar alternateur B Int32 kvar s/o L (-2 147 483 648) - 2 147 483 647
45578 Kvar alternateur C Int32 kvar s/o L (-2 147 483 648) - 2 147 483 647
45580 Kvar alternateur totale Int32 kvar s/o L (-2 147 483 648) - 2 147 483 647
45582 Réservé
