TRIPLIX™ (TRC8022)

Chapter 2 : TECHNICAL DESCRIPTION (continued)

PAGE 7

2-1. FRONT PANEL (continued)

LCD CONTROL

EXIT/MENU:

Switches between Status and Control mode.

ENTER:

Validates a selected item.

CONTROL:

Allows scrolling thru the different menus.

H:

Horizontal control (Image position, PIP position or LOGO position).

V:

Vertical control (Image position, PIP position or LOGO position).

SWITCHER SELECT

1

:

Selection of the switcher #

1.

2

:

Selection of the switcher #

2.

3

:

Selection of the switcher #

3.

NOTE: These is two ways to select many SWITCHER SELECT keys.

Directly: Press successively the needed keys to select many switchers. To unselect a switcher, press again

the corresponding key. This is the default mode.


With the SHIFT key: Press and hold the SHIFT key, then press all the needed SWITCHER SELECT

keys. This mode should be first activate with the LCD menu (CONSOLE > SHIFT
key mode > on).


SHIFT:

Allows to select many SWITCHER SELECT keys (see note above).

TAKE:

Allows to switch the pre-selected input onto the MAIN output with the selected
EFFECT.

T-BAR:

Allows to manually switch the pre-selected input onto the MAIN output with the
selected EFFECT.

2-2. REAR PANEL

ON / OFF:

AC Power switch (O = OFF, I = ON).

POWER INPUT:

Standard IEC connector (100-250 VAC, 50-60Hz automatic).

RS-232

1

:

RS-232 connector (DB9 M) for connecting the switcher #

1.

RS-232

2

:

RS-232 connector (DB9 M) for connecting the switcher #

2.

RS-232

3

:

RS-232 connector (DB9 M) for connecting the switcher #

3.

UPDATE:

Allows updating the TRIPLIX

. See Chapter 6 : UPDATING THE TRIPLIX

.
