Chapter 5 : LCD SCREEN DESCRIPTION (continued) TRIPLIX™ (TRC8022)
PAGE 18
5-5. LCD FUNCTIONS DESCRIPTION (continued)
5-3 [record frame] + ENTER.
This mode allows storing a frame in order to display them at any time during the show.
5-3-1 [size] + ENTER.
Adjust the size of the frame area with H & V. Validate with + ENTER.
5-3-2 [position] + ENTER.
Adjust the position of the frame area with H & V. Validate with + ENTER.
5-3-3 [luma key level] + ENTER.
This function allows to "erasing" the darkest portions of your frame area in order to make special logo
contour. Adjust the luma key level with  + ENTER.
5-3-4 [back. color] + ENTER.
This function allows coloring the "erased portions" of the frame when using the luma key. Select a level
with  + ENTER.
5-3-5 [store]
This function allows storing the frame into one of the 6 frame memories. Select a frame memory with
+ ENTER. The memorization will take about 2 minutes.
5-4 [erase mode] + ENTER.
This function allows erasing the memorized frame and/or the logos. Select an item with  + ENTER.
5-5 [frame quality] + ENTER.
Allows to select the storing quality mode of the frame & logos.
5-5-1 [native (4 frm)] + ENTER.
Allows to store the frame in the native resolution. The frame are not compressed. In this mode 4 frames can
be memorized.
5-5-2 [optimized (6 frm)] + ENTER.
In this mode the frames are compressed. 6 frames can be memorized.
NOTE: When you change the frame quality mode, all the previous frame & logos memorized will be erased.
6[EFFECT]
This menu allows to store an effect in each of the effect keys (USER keys).
6-1 [current effect]
The LCD screen displays the current effect.
c First select an effect key with  + ENTER between:
6-2 [USER 1 key]
.......
6-8 [USER 7 key]
d Then select one of the following effects:
6-x-1 [cut]: allows to switch seamlessly the pre-selected input onto the MAIN output.
NOTE: The opening & closing animation available with this effect is: CUT.
6-x-2 [fading]: allows to fade the pre-selected input to the MAIN output . You can select the duration of the
transition as indicated below:
• [1s]: 1 second transition.
• [3s]: 3 seconds transition.
• [5s]: 5 seconds transition.
• [custom]: Select a duration from 0.5 second up to 25 seconds by 0.5 second steps.
NOTE: The opening & closing animation available with this effect is: FADE.
