TRIPLIX™ (TRC8022) Chapter 5 : LCD SCREEN DESCRIPTION (continued)
PAGE 15
5-5. LCD FUNCTIONS DESCRIPTION (continued)
3-6 [video output] + ENTER. (This menu is available with the OPT-iX-SDTVD1 option only).
NOTE: The following functions act on the optional video outputs only (Composite video, S.VIDEO, YUV and SDI).
3-6-1 [video standard] + ENTER.
Select the output standard for the video outputs with  + ENTER between:
• [NTSC]: NTSC for composite and S.VIDEO outputs. 60Hz frame rate for YUV & SDI outputs.
• [PAL]: PAL for composite and S.VIDEO outputs. 50Hz frame rate for YUV & SDI outputs.
• [NTSCj]: Japan NTSC for composite and S.VIDEO outputs. 60Hz frame rate for YUV & SDI outputs.
3-6-2 [output rate] + ENTER.
Select a function with  + ENTER between:
• [internal]: The video output rate is generated by the device depending of the selected video standard.
• [input # X]: The video output rate is synchronized onto an input of your choice (video source only).
NOTE: If the device is already set in follow mode (LCD menu # 3-2 = follow...). This input and the input
used for the follow mode should be the same.
3-6-3 [flicker adj.] + ENTER.
Select a level of anti-flicker with  + ENTER.
3-6-4 [U/Over scan] + ENTER.
Select a function with  + ENTER between:
• [underscan]: The entire image is visible on the screen. Computer display mode is underscan.
• [overscan]: The image is displayed about 8 % bigger than in underscan mode, to avoid seeing the
corners and the borders. Standard TV display mode is overscan.
3-6-5 [pos settings] + ENTER.
Adjust the video image position with the following functions:
• [size]: Adjust the Horizontal & Vertical size with H and V knobs.
• [position]: Adjust the Horizontal & Vertical position with H and V knobs.
3-6-6 [input stab.] + ENTER.
This function allows to improve the input stability of the referenced input. Select the type of the referenced
source between DVD & VCR.
3-6-7 [color tracking] + ENTER.
This function allows to improve the image color (act only if input stab. = VCR).
3-7 [output status ] + ENTER.
