Chapter 5 : LCD SCREEN DESCRIPTION (continued) TRIPLIX™ (TRC8022)
PAGE 14
5-5. LCD FUNCTIONS DESCRIPTION (continued)
3[OUTPUT] + ENTER.
3-1 [output format] + ENTER.
Select one of the following output formats with  + ENTER.
NOTE: The * symbol placed before the format indicates this format is not available with the selected switcher.
• [848x480]
• [1400x1050]
• [800x600] • [1080p 16/9]
• [1280x720 16/9] • [1600x1200]
• [1024x768] • [720p SDI]
• [1280x768 16/9] • [1080i SDI]
• [1365x768 16/9] • [1080sf SDI]
• [1280x1024] • [1080p SDI]
• [1365x1024]
NOTE: For fixed pixels display devices (DMD, LCD, PLASMA…), always select the output format
corresponding to the native resolution of the display device. Thus, the display device will not have to
scale the image and the result will be better.
3-2 [output rate] + ENTER.
Select an output rate between:
• [internal 23Hz]: The output frame is generated at 23 Hz by the device.
• [internal 25Hz]: The output frame is generated at 25 Hz by the device.
• [internal 29Hz]: The output frame is generated at 29 Hz by the device.
• [internal 50Hz]: The output frame is generated at 50 Hz by the device.
• [internal 59Hz]: The output frame is generated at 59 Hz by the device.
• [internal 60Hz]: The output frame is generated at 60 Hz by the device.
• [internal 72Hz]: The output frame is generated at 72 Hz by the device.
• [internal 75Hz]: The output frame is generated at 75 Hz by the device.
• [follow]:
The output frame is synchronized onto one input signal. Select the needed input with  and
validate with ENTER.
3-3 [output sync] + ENTER.
c Select an output between MAIN & PREVIEW with  + ENTER.
d Select the Output Sync. type with  + ENTER.
• [H&V]: H & V Sync.
• [COMP]: Composite Sync.
• [SOG]: Sync On Green.
3-4 [type of screen] + ENTER.
Select an item with  + ENTER.
• [4/3]: If your image is displayed on a 4/3 wall mounted projection screen shape.
• [16/9]: If your image is displayed on a 16/9 wall mounted projection screen shape.
NOTE: Available only in case of 4/3 output format.
3-5 [test pattern] + ENTER.
c Select an output between MAIN & PREVIEW with  + ENTER.
d Select an item with  + ENTER.
• [no pattern]: No test pattern is displayed.
• [centering]: Displays onto the output a centering pattern (for position and size adjustments).
• [color bar]: Displays onto the output a color bar pattern.
• [V grey scale]: Displays onto the output a vertical grey scale pattern.
• [grid]: Displays onto the output a grid pattern.
• [burst]: Displays onto the output a burst pattern.
• [H grey scale]: Displays onto the output a horizontal grey scale pattern.
