TRIPLIX™ (TRC8022) Chapter 5 : LCD SCREEN DESCRIPTION (continued)
PAGE 13
5-5. LCD FUNCTIONS DESCRIPTION
NOTE: Before entering in the LCD control mode select the switcher you want to adjust, with the ( 1, 2, 3) SWITCHER
SELECTION key. You may select more than one switcher to adjust 2 or 3 switcher at the same time.
1[MODE] + ENTER.
Select a switcher mode between:
• [mixer mode]: Set the device in MIXER mode.
• [matrix mode]: Set the device in MATRIX mode.
2[INPUT] + ENTER.
2-1 [input type] + ENTER.
c Select an input with  + ENTER.
d Select the input signal type with  + ENTER between:
• [SDTV Composite]
• [SDTV SDI 2]
• [SDTV S.VIDEO] • [Computer SOG]
• [SDTV YUV] • [Computer HV/C]
• [SDTV RGBS TTL] • [Computer DVI]
• [SDTV RGB SOG] • [HDTV]
• [SDTV RGBS ana.] • [HDTV SDI 1]
• [SDTV SDI 1] • [HDTV SDI 2]
e Then for [SDTV Composite], and [SDTV S.VIDEO], select the video standard with  + ENTER between:
• [NTSC / PAL / SECAM]: automatic NTSC, PAL, and SECAM standard detection.
• [NTSC]: NTSC standard only.
• [PAL]: PAL standard only.
• [SECAM]: SECAM standard only. • [B & W 50/60 Hz]: Black and White standard.
2-2 [used input] + ENTER.
Select an input and then select an item with  + ENTER between:
• [used]: A signal is connected to the input.
• [unused]: No signal is connected to the input. The input is unused.
2-3 [H sync load] + ENTER.
Select for each input the load of the H Sync. with  + ENTER.
2-4 [VCR mode] + ENTER.
This function allows improving the image contour of low quality VHS tapes. Select [on] with ENTER.
2-5 [synchronized] + ENTER.
This function allows defining the sources which are synchronized together (external genlock). The synchronized
sources can be seamless switched between themselves during an effect (into a PIP for example). This switching
mode is called VIS (Vertical Interval Switching).
2-6 [input status] + ENTER.
Indicates the status of the selected input.
