Chapter 5 : LCD SCREEN DESCRIPTION (continued) TRIPLIX™ (TRC8022)
PAGE 22
5-5. LCD FUNCTIONS DESCRIPTION (continued)
9[SOFTEDGE]
9-1 [merge units]
Allows assembling many device.
9-1-1 [1 2] 3: Allows assembling switchers 1 & 2. Switcher 3 is in stand-alone mode.
9-1-2 1 [2 3]: Allows assembling switchers 2 & 3. Switcher 1 is in stand-alone mode.
9-1-3 [1 2 3]: Allows assembling switchers 1, 2 & 3.
9-1-4 [1] [2] [3]: All switchers are in stand-alone mode.
9-2 [multiscreen]
Allows to select the input to be extended.
9-3 [covering]
Allows to adjust the covering size.
9-4 [blending]
Allows to activate/deactivate the softedge.
9-5 [test pattern]
Allows to activate the covering pattern.
9-6 [black level]
Allows to adjust the black level. Select one switcher at a time and do the adjustments.
9-6-1 [start pos.]: Allows to remove the white lines at the junction of the covering area (right edge).
9-6-2 [end position]: Allows to remove the white lines at the junction of the covering area (left edge).
9-6-3 [red]: Adjustment of the red level.
9-6-4 [green]: Adjustment of the green level.
9-6-5 [bleu]: Adjustment of the bleu level.
