6
49-5000712 Rev. 1
Using the Air Conditioner - Features
USING THE
AIR CONDITIONER
To Adjust Fan Speeds
Press the Fan Speed button to select the FAN Speed in
four steps - Auto, Low, Med, or High. Each time the button is
pressed, the fan speed mode is shifted.
For some models, the fan speed can not be adjusted under
HEAT mode. In DRY mode, the fan speed is controlled at low
automatically.
Sleep
Press the Sleep button to initiate the sleep mode. In this mode,
the selected temperature will increase (cooling) or decrease
KHDWLQJE\ƒ)ƒ&PLQXWHVDIWHUWKHPRGHLVVHOHFWHG
The temperature will then increase (cooling) or decrease
KHDWLQJE\DQRWKHUƒ)ƒ&DIWHUDQDGGLWLRQDOPLQXWHV
This new temperature will be maintained for 7 hours before it
returns to the originally selected temperature. This ends the
Sleep mode and the unit will continue to operate as originally
programmed. The Sleep mode program can be cancelled at any
time during operation by pressing the
Sleep button again.
Check Filter
Press the Filter button to initiate this feature. This feature is a
reminder to clean the air filter for more efficient operation.
The LED (light) will illuminate after 250 hours of operation. To
reset after cleaning the filter, press the
Filter button and the
light will go off.
Eco - Energy Saver
Press the Eco button to initiate this feature. This feature is
available on COOL, DRY, AUTO , (only AUTO-COOLING and
AUTO-FAN ) modes. The fan will continue to run for 3 minutes
after the compressor shuts off.
The fan then cycles on for 2 minutes at 10 minute intervals until
the room temperature is above the set temperature, at which
time the compressor turns back on and Cooling starts.
Timer: Auto Start / Stop
Ŷ When the unit is on or off, first press the Timer button, the
TIMER ON indicator light illuminates. It indicates the Auto
Start program is initiated.
Ŷ When the time of TIMER ON is displayed, press the Timer
button again, the TIMER OFF indicator light illuminates. It
indicates the Auto Stop program is initiated.
Ŷ Press or hold the + or – button to change the Auto time by 0.5
hour increments, up to 10 hours, then at 1 hour increments up
to 24 hours. The control will count down the time remaining
until start.
Ŷ The selected time will register in 5 seconds, and the
system will automatically revert back to display the previous
temperature setting or room temperature when the unit is on.
(When the unit is off, there is no display.)
Ŷ Turning the unit ON or OFF at any time or adjusting the timer
VHWWLQJWRZLOOFDQFHOWKH$XWR6WDUW6WRSWLPHGSURJUDP
To Select the Operating Mode
To choose operating mode, press the Mode button. Each time
you press the button, a mode is selected in a sequence that
goes from
AUTO, COOL, DRY, HEAT (on some models) and
FAN only. The indicator light above will be illuminated and
remain on once the mode is selected.
The unit will initiate the Energy Saver function under COOL,
DRY, AUTO (only AUTO-COOLING and AUTO-FAN ) modes.
To Operate on Auto Feature:
Ŷ When you set the air conditioner in AUTO mode, it will
automatically select cooling, heating (on some models)or
fan only operation depending on what temperature you have
selected and the room temperature.
Ŷ The air conditioner will control room temperature
automatically to the temperature set point.
Ŷ In this mode, the fan speed cannot be adjusted, it starts
automatically at a speed according to the room temperature.
To Operate on Fan Only:
Ŷ8VHWKLVIXQFWLRQRQO\ZKHQFRROLQJLVQRWGHVLUHG<RXFDQ
choose any fan speed you prefer.
Ŷ'XULQJWKLVIXQFWLRQWKHGLVSOD\ZLOOVKRZWKHDFWXDOURRP
temperature, not the set temperature in the cooling mode.
Ŷ,Q)DQRQO\PRGHWKHWHPSHUDWXUHLVQRWDGMXVWDEOH
To Operate on Dry Mode:
Ŷ,QWKLVPRGHWKHDLUFRQGLWLRQHUZLOOJHQHUDOO\RSHUDWHLQ
the form of a dehumidifier. Since the conditioned space is a
closed or sealed area, some degree of cooling will continue.
Fahrenheit vs. Celsius
To change the temperature display from Fahrenheit to Celsius, press – and + together and hold for 5 seconds.
