14.0 Maintenance
Disconnect from the power supply before carrying out maintenance work.
Maintenance should be restricted to occasional removal of dust
and lint around the unit. The outer surface may be wiped over
with warm water and mild detergent taking care to avoid water
entering the grille areas.
Replacing the Filter
Periodically the filter will need to be cleaned, and the control
system on this product will display ‘FILT’ when it is time for the
filter to be checked. To remove the ‘FILT’ display, press and hold UP
for 5 seconds. Filters can be easily removed for cleaning as shown
below. See spare parts list section if replacement filters are needed.
Remove the old filter Place the new filter
15.0 Accessories
Connection & adjustment set
(2-Pipe Kit)
Connection & adjustment set
(4-Pipe Kit)
Pressure independent balancing and
control valve with 230V actuator
Pressure independent balancing and control
valves (x2) with 230V actuators
AZ5-MCAC5001001
AZ5-MCAC5001000
Condensate Pump Kit 230V Condensate pump kit including
mounting brackets, float switch, and 2m
flexible tube for condensate removal
AZ5-MCAC5001010
Description Technical information Part No
