12.0 Control System Set-up and Operating Instruction
General Description
The electronic control system on this unit provides a wide range of
options that can be selected according to system complexity and
operating requirements.
The unit is factory set to ‘Easy Mode’ giving thermostatic
temperature control, fan only option and clock function.
Additional functions are available if necessary from the Full
operating mode menu.
A range of additional parameters and features can be changed or
activated in a further set up menu should these be required.
Easy Mode
Turn on Electrical Supply
Easy Mode
(Factory Default)
Full Mode
Use ( ) and ( ) keys to select
operating mode (refer to
section 12.2 for details)
Setup parameters
(refer to section 12.3
for details)
Full Mode
Select Clock
and set time
Select Comfort setting
Set room temperature to
desired setting (default 21°C).
Fan runs in heating/cooling
Fixed fan setting
Comfort setting
Clock setting
Power on/off
Fixed fan setting
Comfort setting
Auto setting
Night set-back setting
Holiday setting
Power on/off
Clock setting
Program menu
Auto
P
Press & hold (+) & (-) for 5 secs
to change between modes
Press & hold (+) & (-)
for 5 secs to change
between modes
Select Auto mode and
press (OK) for 10 secs
12.1 Unit Operation
Use ( ) and ( ) keys to choose from the operating modes
described in section 12.2. A function is selected when the relevant
icon is highlighted by .
Flow Rates/Pressure Losses
100 1.4 2 2.8 3.2 3.8
150 2.8 4.2 5.8 6.4 7.4
220 5.8 8.2 11 12.2 14.2
330 12.2 17 22.2 24.4 28.4
500 26 35.6 45.8 49.8 57.4
See our Easy Mode
video on our website.
