16
All VIDO models require an electrical supply of 220-240V 50Hz
fused at 3A.
Electrical Data
The VIDO should be sized based on “normal” outputs.
Flow Rates/Pressure Losses
100 0.7 1 1.4 1.6 1.9
150 1.4 2.1 2.9 3.2 3.7
220 2.9 4.1 5.5 6.1 7.1
330 6.1 8.5 11.1 12.2 14.2
500 13 17.8 22.9 24.9 28.7
750 27.5 36.5 46.2 49.8 57.1
Pressure Loss (kPa)
2 Pipe Heating/Cooling & 4 Pipe Cooling
100 1.4 2 2.8 3.2 3.8
150 2.8 4.2 5.8 6.4 7.4
220 5.8 8.2 11 12.2 14.2
330 12.2 17 22.2 24.4 28.4
500 26 35.6 45.8 49.8 57.4
4 Pipe Heating
Flow
(l/h)
600x800 600x1000 600x1200 600x1400 600x1600
Air Flow Rates
Normal 90 135 180 225 270
Heating Medium 148 221 295 369 443
Boost 247 370 493 616 740
Normal 65 98 130 163 195
Cooling Medium 110 165 220 275 330
Boost 202 302 403 504 605
Air Flow m 3 /h
Condition
600x800 600x1000 600x1200 600x1400 600x1600
Fan
Speed
11.0 Technical Data (continued...)
Model
Dimensions
Model
Nominal Height
(mm)
Depth
(mm)
Length
(mm)
600x800 600 153 800
600x1000 600 153 1000
600x1200 600 153 1200
600x1400 600 153 1400
600x1600 600 153 1600
600x8000 24.8 37.7 47.9
600x1000 27 35.8 47.9
600x1200 24 40.5 51.7
600x1400 24.9 35.5 54.8
600x1600 27 35 56.3
Sound Levels
Sound levels tested in accordance with ISO 3741.
Note: 2 pipe water content = 2 pipe heating/cooling
or 4 pipe cooling and 4 pipe water content = 4 pipe heating.
Sound Pressure (dBA) (at 2.5m)
Normal Medium Boost
600x800 32 0.66 0.33 22.8 24.8
600x1000 35 0.92 0.46 27.7 30.1
600x1200 44 1.19 0.6 32.5 35.3
600x1400 53 1.45 0.73 37.5 40.7
600x1600 65 1.72 0.86 42.6 46.2
Model
Motor
Power
(W)
2 Pipe
Water
Content (i)
4 Pipe
Water
Content (i)
2 Pipe
Unpacked
Weight (kg)
4 Pipe
Unpacked
Weight (kg)
Weight, Water Content and Motor Power
