23
Remove door strike and door strike label from dryer cabinet.
Insert the door strike into hole where door strike label was
removed and secure with screw. Cover original door strike
hole with door strike label and press firmly into place.
Remove door strike and door
strike label
10.
Door strike label Door strike
Remove and transfer plugs
11.
Remove the 4 screws that attach 2 plugs on the left side.
Transfer plugs to opposite side using the same 4 screws.
Insert screws in hinge holes on
dryer cabinet
12.
NOTE: 2 people may be needed to reinstall door.
Insert screws into the bottom holes on left side of dryer
cabinet. Tighten screws halfway. Position door so large end of
door hinge slot is over screws. Slide door up so screws are in
bottom of slots. Tighten screws. Insert and tighten top screws
in hinges.
Check door strike alignment
13.
Close door and check that door strike aligns with door catch.
If it is needed, slide door catch left or right within slot to
adjust alignment.
Troubleshooting
See the Use and Care Guide or visit our website and
reference “Frequently Asked Questions” to possibly avoid
the cost of a service call.
