¼ The operations described below apply to deck A and deck B alike.
¼ Switch on your amplifier or receiver.
¼ Set the Function Selector on your amplifier or receiver to the TAPE or Tape monitor position.
¼ The numbers in the illustration below depict the order in which operation steps are carried out.
PLAYBACK
This Stereo Cassette Deck contains an automatic tape selector which
automatically selects the optimum bias and equalization for the tape
in use. This is accomplished by detection of tape type detection holes
in the cassette housing.
Detection holes for
chrome tape
Detection holes
for metal tape
¼ If a tape without tape type detection holes is used, the deck
will be set for normal tapes.
AUTOMATIC TAPE SELECTION
RESET
MIN
–
PHONES
CONTROL
PITCH PLAY +
RESET
COUNTER COUNTER
REC/PLAY
EJECT
A
PLAY PLAY
HIGH PAUSE NORMAL REC MUTE RECORD REC LEVEL SYNC REV
STOP
POWER ON/OFF
STOP
CCONT. PLAY
B
OFF
PLAY
OFF
REC
C
B
REV. MODE
DOLBY NR
DOUBLE CASSETTE DECK SD4050
EJECT
TIMER
MAX
DUBBING SPEED
AUTO TAPE SELECT/HIGH SPEED DUBBING
AUTO REVERSE
AUTO TAPE SELECT/HIGH SPEED DUBBING
AUTO REVERSE
r e
q w u y t
1. Press the POWER switch q to the ON ( ) position.
2. Press the EJECT ( ) button w to open the cassette compartment
cover e.
3. Load the cassette tape and close the cassette compartment cover
e.
4. When listening to a tape that has been recorded with Dolby noise
reduction, set the DOLBY NR switch r to match the system used
at the time of recording.
6. Press the PLAY button y ( or ) to being playback.
OFF
C
B
DOLBY NR
5. Select the type of tape transport with the REV MODE switch t.
REV. MODE
Mode
To listen to one side only
To listen to playback of both sides
To listen to continuous play back
of both sides and both decks.
Switch position
7. Press the STOP ( ) button u to stop the playback.
¼ In the continuous playback mode (REV MODE set to ),
playback of both tape sides will be repeated 5 times and then
stop automatically.
¼ If different types of Dolby noise reduction are used for record
and playback, playback response will be adversely effected.
¼ When power is turned off during tape transport, it may not be
possible to remove the cassette by pressing the EJECT ( )
button. In this case, turn on power again before you press the
EJECT (
)button.
Transport Direction
Forward
Reverse
Indicator
