A too high recording level can saturate the tape and cause distortion.
On the other hand, if the recording level is set too low, soft passages
will be marked by residual noise. A proper recording level is the
single most important factor for making well balanced recordings.
Guideline for maximum recording level
TYPE q (Normal)
TYPE w (High position)
TYPE r (Metal)
0 dB level on peaks
ѿ1 dB level on peaks
ѿ3 dB level on peaks
Note:
The optimum recording level differs depending on the program
source and the type of tape used.
1. Press the POWER switch q to the ON ( ) position.
2. Load the cassette tape to be played on deck A and the one to be
recorded in deck B w.
3. Select the position of the REV MODE switch e.
4. To being normal speed dubbing, press the DUBBING SPEED
HIGH button r. The NORM DUB indicator will light at this timee.
The HIGH DUB indicator will light at this time.
5. To stop dubbing, press the STOP ( ) button t of deck A or deck
B.
¼ When dubbing, the recording level and the Dolby NR recording
will be the same as those of the playback tape, regardless of
the positions of the REC LEVEL control and the DOLBY NR
button.
¼ When listening to the playback sound suring normal speed
dubbing, the DOLBY NR switch remains off even if it is
pressed.
¼ Operation using the REC MUTE and PAUSE ( ) buttons y,
u of deck B is permitted during normal speed dubbing.
DUBBING (from deck A to deck B)
REV. MODE
Reverse mode Operation
Dubbing is performed only for one side.
The decks stop when either deck A or B
reaches the end of the tape.
The tape direction is reversed on each deck
when they reach the end of the tape.
(This is convenient for dubbing to a tape with
a different length.)
or
1. To record a 4-second blank section during recording:
Press the REC MUTE button. A 4-second blank will be recorded
and the deck will enter the recording Pause mode.
2. To record a 4-second blank section during the recording Pause
mode:
Press the REC MUTE button from the recording Pause mode. A 4
second blank will be recorded and the deck will enter the
recording Pause mode again.
¼ Switch on the amplifier or receiver.
¼ Set the Tape Monitor or Function switch on your amplifier or
receiver to the TAPE/TAPE monitor position.
RESET
MIN
–
PHONES
CONTROL
PITCH PLAY +
RESET
COUNTER COUNTER
REC/PLAY
EJECT
A
PLAY PLAY
HIGH PAUSE NORMAL REC MUTE RECORD REC LEVEL SYNC REV
STOP
POWER ON/OFF
STOP
CCONT. PLAY
B
OFF
PLAY
OFF
REC
C
B
REV. MODE
DOLBY NR
DOUBLE CASSETTE DECK SD4050
EJECT
TIMER
MAX
DUBBING SPEED
AUTO TAPE SELECT/HIGH SPEED DUBBING
AUTO REVERSE
AUTO TAPE SELECT/HIGH SPEED DUBBING
AUTO REVERSE
w
q u y r
w t
e
PROPER RECORDING LEVEL
REC MUTE AND REC PAUSE BUTTON
3. To cancel recording of blank space:
Press the PAUSE ( ) button. Blank space recording will be
canceled and the deck enters the recording Pause mode.
4. To extend the blank section with another 4 seconds or more:
Simply press the REC MUTE button and the blank section will be
increased with another 4 seconds.
