Marantz SD4050 - Manuel (Page 13)

13
ENGLISH
FRAN
Ç
AIS
REMOTE CONTROL
z
A/B button Mechanism select buttons (DECK A/B):
Press to select the deck mechanism, Deck A or Deck B, to be
controlled.
x
(REC PAUSE) button:
Press this button to enter the recording pause mode from the
recording or recording mute mode. This button can only be used
during recording. See page 9.
c
REC button:
Press the REC button, the deck enters the Recording Pause mode.
See page 9.
v
(Play button):
Press to playback tape.
b
(Fast rewind button):
Press for fast rewind.
n
RESET button:
Press to tape counter reset.
m
REC MUTE button:
Press the REC MUTE button, the Recording Pause mode will start
Auto Rec Mute, and a 4-second silent space is recorded onto the
tape. See page 9.
,
(DIRECTION) button:
After starting playback, press the forward ( ) or reverse ( ) to
select the top playback direction.
.
(Fast forward button):
Press for fast forwarding.
⁄0
(STOP) button:
Press to cancel any operation modes and stop the tape travel of the deck.
REC
RESET
RC455SD
DECK
REC MUTE
A B
z
x
c
n
m
,
.
⁄0
v
b
USING THE REMOTE CONTROL UNIT
1. Remote control
Operate the remote control unit (RC455SD) within a distance of
approx.
5 m from the infrared signal reception window (remote sensor) on the
front of the CASSETTE DECK.
Remote control operation may not be possible if the remote control
unit's transmitter is not pointing in the direction of the remote sensor
or if there is an obstruction between the transmitter and the remote
sensor.
2. Loading batteries
Batteries in this remote control unit have a life of approximately 1 year
under normal operating conditions. When the remote control unit is
not to be used for an extended period of time, remove the batteries.
Also, when you notice that the batteries are starting to run down,
replace them as soon as possible.
(1) Remove the battery cover.
(2) Insert the batteries with correct e/ȕ orientation.
(3) Close the battery cover until it clicks shut.
60 °
Approx. 5m
Remote control operating range
Remote control unit
Remote control unit Rear side
Two AA-size (R6 batteries)
Cassette deck
