Polaris 2005 Victory Hammer - Canada - Manuel (Page 106)

A
Fast Idle
Position
Fast Idle
Lever
B
102
MAINTENANCE
Fast Idle Lever and Cable
1. Move the fast idle lever. It should move smoothly from
its rest position to its completely open position and back
again. Measure fast idle lever free-play (A), which is
the amount of lever movement from the rest position to
the point of cable resistance.
Specification: 3-6mm, 1/8-1/4 in.
Fast Idle Lever Freeplay Adjustment
1. If adjustment is necessary, remove seat (page 122) and
fuel tank (page 100).
2. Loosen the fast idle cable adjuster jam nut (B).
3. Turn the cable adjuster in or out until freeplay at the lever
is 1/8-1/4 inch (3-6 mm).
4 Tighten the adjuster jam nut securely and reinstall the fuel
tank and operator’s seat.
5. Start engine and let it idle with transmission in NEUTRAL
with fast idle lever in the normal run position (off).
6. Turn the handlebars from full right to full left. If engine
RPM increases when bars are turned, re-check throttle
cable and fast idle cable adjustments, cable condition, and
routing. If problem persists contact your VICTORY dealer.
