154
SPECIFICATIONS
Model Year 2005 HAMMER
Engine
Engine Model Number MCVT1634D 2005
Configuration 50_ V-Twin 4 Stroke
Displacement 100 cu in (1634 cc)
Cooling System / Oiling System Air & Oil / Wet Sump
Compression Ratio 9.8:1
Valve Train SOHC - 4 Valves Per Cylinder With Hydraulic Lifters
& Hydraulic Cam Chain Adjusters
Bore and Stroke 101 x 102 mm
Throttle Body Bore 44 mm
Exhaust System Dual-Large Bore Slash-Cut with Common Volume
Spark Plug / Gap NGK CPR6EA-9 .032 in (0.8 mm)
Chassis
Front Suspension Type / Travel 43mm Inverted Telescopic Fork
5.1 in (13 cm)
Rear Suspension Type/Travel Single, Monotube Gas,
Preload Adjustable / 3.9 in (10 cm)
Swingarm Forged and Cast Aluminum
With Rising Rate Linkage
Front Brakes Dual 300 x 5 mm Floating Rotor
4 Piston Calipers
Rear Brakes Single 300 x 5 mm Floating Rotor
2 Piston Caliper
NOTE: Dimensions and specifications may vary with features, options and accessories.
