105
MAINTENANCE
Clutch
Lubricate Clutch Lever
1. Remove right side cover.
2. Slide the rubber cover off the cable adjuster, and loosen the adjuster jam
nut (see page 106.)
3. Turn the cable adjuster all the way in to provide maximum lever free
play.
4. Remove clutch lever pivot nut (1), plate (2) and pivot screw (3).
5. Disconnect the clutch cable from the clutch lever.
6. Remove any old grease and dirt from the clutch lever and lever housing.
7. Lubricate the clutch lever and lever pivot screw with VICTORY All
Purpose Grease or equivalent.
8. Reconnect the clutch cable and reinstall the lever and lever pivot screw.
9. Install plate and nut.
10. Hold pivot screw in place and torque nut to 40 in-lbs (5 Nm).
11. Adjust clutch freeplay (page106).
1
2
3
AP
