101
MAINTENANCE
Fuel System
Fuel can damage painted surfaces and plastic parts. Wipe spilled fuel immediately from the motorcycle
using a clean, dry, soft cloth.
Caution
5. Loosen hose clamp and disconnect the fuel supply hose from fuel
rail (2).
6. At the rear left side of the tank, disconnect the tank vent hose
(California models) and the water drain hose.
7. Carefully remove fuel tank.
8. To reinstall the fuel tank, reverse the removal steps, routing fuel
supply hose to the right of breather hose.
9. Torque the fuel supply hose clamp.
Torque: 20 in-lb. (2.5 Nm)
10. Reinstall the fuel tank mounting screws.
Torque: 35 ft-lb. (47.5 Nm)
11. Reinstall the seat.
Replace Fuel Filter
The fuel filters are attached to the electric fuel pump located inside the fuel tank. Fuel filter condition is associated
with engine performance and fuel economy. For fuel filter replacement procedures and special tools required, see
the VICTORY Service Manual or contact an authorized VICTORY dealer.
