122
MAINTENANCE
Seat Removal and Installation
There are two separate seats, the operator’s seat and the passenger seat. It is not necessary to remove the passenger
seat for regular maintenance. The passenger seat mounting screws are located on each side of the seat and are
accessed from the top after removing the passenger seat fairing.
Always make sure the seats are securely fastened before riding the motorcycle. A loose seat could
cause a sudden shift in riding position, causing loss of control.
WARNING
Seat Removal
1. Remove the passenger seat cowl by pulling upward on
the sides and rearedge of the cowl (see arrows).
2. Remove the (3) 5mm socket head screws from each side
of the seat.
3. Lift the rear of the seat and pull rearward to disengage
the tab at the front of the seat.
4. Remove the seat.
Seat Installation
5. Slide the tongue of the seat into the rubber mount at rear
of fuel tank.
6. Align the screw holes at the rear of seat.
7. Ensure the front seat mount is engaged in the front
rubber mount, then install the screws and tighten securely.
8. Reinstall passenger seat cowl.
1. Remove Rear Cowl
2. Remove (3) screws. 3. Lift Rear of Seat, Pull
Rearward
1
2
