31
COMPONENT IDENTIFICATION
LEFT SIDE VIEW
1. Front Fork
2. Front Turn Signal
3. Headlamp
4. Air Filter
5. Spark Plug (2)
6. Ignition Switch
7. Left Side Cover
8. Battery (under side cover)
9. Rear Turn Signal
10. Taillight
11. Rear Axle Adjuster (1 each side)
12. Rear Brake Caliper
13. Passenger’s Foot Rest
14. Evaporative Emissions Canister - California Models
(lower left by swingarm)
15. Oil Filter
16. Sidestand
17. Operator’s Foot Rest
18. Gear Shift Lever
19. Horn
20. Front Brake Caliper
1
7
10
6
2
3
9
11
12 14 15 16 17 18 19 20 13
8
4 5
