8
2. Remove the foot from the right front spacer by removing the
#8-18 x ³⁄
8
" screw.
NOTE: Do not remove the spacer.
A. Spacer
B. Foot
C. #8-18 x ³⁄
8
" screw
3. Rotate the foot 90° so the short side of the foot is positioned
toward the top of the oven.
4. Reinstall the foot to the spacer using the #8-18 x ³⁄
8
" screw
previously removed.
5. In the same manner, remove, rotate and reinstall the feet
on the right rear, left front, and left rear of the oven.
6. Using 2 or more people, place the oven in its upright
position.
7. Go to the “Make Electrical Connection” section.
Double Ovens
The positioning of the oven feet allow a double oven to be
installed in a cutout height between 48 7 ⁄
8
" (124.1 cm) and
52³⁄ 16 " (132.6 cm). Refer to the following instructions to position
the feet for the size of your cabinet cutout.
Cutout height is between 48 7 ⁄
8
" (124.1 cm)
and 50 7 ⁄
16
" (128.1 cm)
The oven feet do not need to be installed. The oven is
configured correctly as received.
NOTE: Do not remove the spacers.
Go to the “Make Electrical Connection” section.
A. Spacers
A
B
C
A
A
