4
Product Dimensions – Double Ovens
27" (68.6 cm) models
A. 51³⁄
16
" (130.0 cm) max. overall
height
B. 25 7 ⁄
16
" (64.6 cm) max. recessed
width
C. 48¹³⁄
16
" (124.0 cm) recessed
height
D. 23¹⁄
4
" (59.1 cm) max. recessed
depth
E. 27" (68.6 cm) overall width
Cabinet Dimensions – Double Ovens
Double Oven Installed in Cabinet
27" (68.6 cm) models
A. 27" (68.6 cm) min. cabinet
width
B. 1" (2.5 cm) top of cutout to
bottom of upper cabinet door
C. 14³⁄
4
" (37.5 cm) bottom
of cutout to floor is
recommended. 4"–14³⁄
4
"
(10.2–37.5 cm) bottom of
cutout to floor is acceptable.
D. 25¹⁄
2
" (64.8 cm) cutout width
E. 1¹⁄
2
" (3.8 cm) min. bottom of
cutout to top of cabinet door
F. 50¹⁄
4
" (127.6 cm)*
recommended cutout height
G. 24" (60.7 cm) cutout depth
C
B
A
E D
F
E
A
D
G
B
C
30" (76.2 cm) models
A. 51³⁄
16
" (130.0 cm) max. overall
height
B. 28½" (72.4 cm) max. recessed
width
C. 48¹³⁄
16
" (124.0 cm) recessed
height
D. 23¹⁄
4
" (59.1 cm) max. recessed
depth
E. 30" (76.2 cm) overall width
30" (76.2 cm) models
A. 30" (76.2 cm) min. cabinet
width
B. 1" (2.5 cm) top of cutout to
bottom of upper cabinet door
C. 14³⁄
4
" (37.5 cm) bottom
of cutout to floor is
recommended.
4"–14³⁄
4
" (10.2–37.5 cm)
bottom of cutout to floor is
acceptable.
D. 28¹⁄
2
" (72.4 cm) cutout width
E. 1¹⁄
2
" (3.8 cm) min. bottom of
cutout to top of cabinet door
F. 50¹⁄
4
" (127.6 cm)*
recommended cutout height
G. 24" (60.7 cm) cutout depth
* NOTE: The cutout height can be between 48 7 ⁄
8
" (124.1 cm)
and 52³⁄
16
" (132.6 cm) for double ovens.
