Analog Way V-Scale - VSL121 Manuel d'utilisation
Page 35
VSL range
APPENDIX A / ANNEXE A
PAGE 35
COMMAND RESPONSE
COMMAND DESCRIPTION
VALUE /VALEUR
COMMANDE RÉPONSE
DESCRIPTION DE LA COMMANDE
TYPE
MIN MAX
DESCRIPTION
AUDIO COMMANDS / COMMANDES DU MENU AUDIO
RO
AMOD
Auto follow or breakaway mode.
Rd/Wr
0
1
0 = auto follow
1 = breakaway
RC
ACH
Audio input selection.
Rd/Wr
1
5
• VSL121 & VSL241:
1 = INPUT #1 2 = INPUT #2 3 = INPUT #3
4 = INPUT #4 5 = INPUT #5
• VSL300:
1= VIDEO
2 = COMPUTER
CONTROLS COMMANDS / COMMANDES DE CONTRÔLE
xU VERU
Device
version.
Rd
0 65535 Example: 104 = Version 1.4
xI I_
Identification
number.
Rd
0 65535 Value displayed in hexadecimal in the device.
yo OPT
Options
available.
Rd
0 65535 0 = without option.
QE
EPD
2:2 pull down correction.
Rd/Wr
0
1
0 = off
1 = auto.
oT OST
Black
delay
Rd/Wr
0
2
0 = short
1 = medium
2 = long
yl
LOCK
Key locking.
Rd/Wr
0
1
0 = unlocks
1 = locks
sT
STBT
Standby delay
Rd/Wr
0
1
0 = OFF
1 = 1 min
255 = 255 min
sS STBY
Standby
mode
Rd/Wr
0
1
0
= standby inactive 1 = standby active
ye
EPOS
Erase memories.
Rd/Wr
0
1
1 = erase all memories (automatic reset).
Y
FRES
DEFAULT VALUE.
Rd/Wr
0
1
1 = Default value action (automatic reset).
OTHERS COMMANDS / COMMANDES DIVERSES
yS
STO
Image parameters storing.
Rd/Wr
0
1
1 = STORE action (automatic reset).
? DEV
Device
type.
Rd
0 65535
32 = VSL121
33 = VSL241
40 = VSL300
COMMUNICATION COMMANDS / COMMANDES DE COMMUNICATION
ne LANE
Communication
port
selection
Rd/Wr
0
1
0 = RS232
1 = LAN
nr
LANR
Reset of the LAN parameters.
Rd/Wr
0
1
1 = reset.
ns
LANS
Store the LAN parameters.
Rd/Wr
0
1
1 = store.
na ADIP
IP address and port selection (for
modification)
Rd/Wr
0 3
0 = all IP address / ports
1 = IP local address / local port
2 = IP remote address / remote port
3 = IP gateway address.
nw IPA_
First byte of the address selected by the
na command.
Rd/Wr
0 255
nx IPB_
Second byte of the address selected by
the na command.
Rd/Wr
0 255
ny IPC_
Third byte of the address selected by the
na command.
Rd/Wr
0 255
nz IPD_
Forth byte of the address selected by the
na command.
Rd/Wr
0 255
np PORT
Number of the port (local or remote)
selected by the na command.
Rd/Wr
0 65500
local port: 10000 to 10999.
remote port: 0 to 65500.
nk NTMK
Netmask.
Rd/Wr
0
24
Value = number of bit to 0 (from right).
example: 2
255.255.255.252
3
255.255.255.248.............
8
255.255.255.0.............
24
255.0.0.0
nt
TCP
Protocol selection.
Rd/Wr
0
1
0 = UDP
1 = TCP
FRAME ALERT COMMANDS / COMMANDES DE FRAME ALERT
fM
FAMD
Frame alert mode
Rd/Wr
0
3
0 = normal mode
1 = capture mode
3 = erasing mode
fX FAEX
Erasing/storing
mode
Rd/Wr
0 1
1
=
erasing/storing
fR
FARC
Frame alert storing status
Rd
0
1
0 = empty memory
1 = frame memorized
fA
FAAU
Automatic frame alert activation
Rd/Wr
0
1
0 = not activate
1 = activate
fs FASW
Frame
alert
activation
Rd/Wr
0
1
0 = switch off the frame alert
1 = display the frame alert.
fS
FAST
Frame alert display status
Rd
0 1
0 = frame alert not displayed.
1 = frame alert displayed.
NOTE: Rd = Read only command / Commande de lecture.
Rd/Wr = Read and write command / Commande de lecture et d'écriture.
