APPENDIX A / ANNEXE A VSL range
PAGE 34
A-4: COMMANDS AND RESPONSES TABLE A-4: TABLE DES COMMANDES ET RÉPONSES
COMMAND RESPONSE
COMMAND DESCRIPTION VALUE /VALEUR
COMMANDE RÉPONSE DESCRIPTION DE LA COMMANDE
TYPE
MIN MAX DESCRIPTION
FRONT PANEL COMMANDS / COMMANDES DE LA FACE AVANT
CC CH Selected input. Rd 0 5
CN CHN Input selection. Rd/Wr 0 5
• VSL121 & VSL241:
1 = INPUT #1 2 = INPUT #2 3 = INPUT #3
4 = INPUT #4 5 = INPUT #5
• VSL300:
1= VIDEO
2 = COMPUTER
Z FRZ FREEZE. Rd/Wr 0 1 0 = inactive 1 = active.
FO OBLK BLACK output screen selection. Rd/Wr 0 1 1 = BLACK.
INPUT COMMANDS / COMMANDES D'ENTRÉE
PC PCH Input selection for adjustment. Rd/Wr 0 5
0 = All inputs 1 = INPUT #1
2 = INPUT #2 3 = INPUT #3
4 = INPUT #4 5 = INPUT #5
PE PEN Input disabling (according to PCH). Rd/Wr 0 1 0 = Input disable 1 = Input enable
PR PRGB
Input signal type selection. (according
to PCH).
Rd/Wr 0 7
0 = SDTV Composite 1 = SDTV S.VIDEO
2 = SDTV YUV
3 = SDTV RGBS TTL.
4 = SDTV RGsB 5 = SDTV RGB ana.
6 = reserved 7 = Computer
PI PSTD
Input standard selection (according to
PCH).
Rd/Wr 0 4
0 = NTSC / PAL / SECAM
1 = NTSC
2 = PAL
3 = SECAM 4 = Black & White
PP PPRC VCR mode (according to PCH). Rd/Wr 0 1 0 = OFF 1 = ON
PM PM Input priority Rd/Wr 0 2
0 = no priority
1 = video priority
2 = computer priority
OUTPUT COMMANDS / COMMANDES DE SORTIE
oY OTYP Output type selection (VSL241) Rd/Wr 0 3
1 = analog 2 = DVI
3 = analog & DVI
FM OFTM Output format selection. Rd/Wr 0 10
0 = 800x600 1 = 1024x768
2 = 1280x1024 3 = 1400x1050
4 = 1600x1200 5 = reserved
6 = 852x480 7 = 1280x768
8 = 1366x768 9 = 720p
10 = 640x480
XR REFR Output rate mode Rd/Wr 0 1 0 = internal rate 1 = follow input
oR ORTM Output frame rate selection. Rd/Wr 0 3
0 = 50 Hz 1 = 60 Hz
2 = 72 Hz (VSL241) 3 = 75 Hz (VSL241)
op OPAT Centering pattern Rd/Wr 0 1 0 = OFF 1 = ON
FY OSYN Output sync selection. Rd/Wr 0 2
0 = H &V 1 = Composite
2 = SOG (Sync On Green).
IMAGE COMMANDS / COMMANDES DU MENU IMAGE
H HP Horizontal position. Rd/Wr 0 255
V VP Vertical position. Rd/Wr 0 255
W HW Horizontal size. Rd/Wr 0 255
S VS Vertical size. Rd/Wr 0 255
QA ASP Input aspect ratio selection. Rd/Wr 0 2
0 = 4/3 standard 1 = 16/9 letterbox
2 = WS anamorphic.
QS OASP Output aspect ratio selection Rd/Wr 0 2
0 = Standard 1 = Full screen
2 = Crop
B BRG Brightness adjustment (video). Rd/Wr 0 255
D CON Contrast adjustment (video). Rd/Wr 0 255
O COL Color adjustment (video). Rd/Wr 0 255
T HUE Hue adjustment (video NTSC). Rd/Wr 0 255
QO OVR Underscan / overscan (video). Rd/Wr 0 1 0 = underscan 1 = overscan
QP PRO Sharpness adjustment (video). Rd/Wr 0 7
0 = standard level 1 = level 1
2 = level 2.................. 7 = level 7.
yP PRES PRESET. Rd/Wr 0 1 1 = PRESET action (automatic reset).
NOTE: Rd = Read only command / Commande de lecture. Rd/Wr = Read and write command / Commande de lecture et d'écriture.
