Di-VentiX™ Chapter 6 : Di-VentiX & REMOTE KEYPAD SCREEN DESCRIPTION (continued)
PAGE 59
6-5. FRONT PANEL SCREEN FUNCTIONS DESCRIPTION (continued)
6-x-8 [Slide]: Allows to switch the pre-selected input onto the MAIN output with a horizontal slide effect.
First select a horizontal wipe effect with  + ENTER between:
• [from left]: From left to right.
• [from right]: From right to left.
• [from top]: From top to bottom.
• [from bottom]: From bottom to top.
Then select the duration of the transition.
• [1s]: 1 second transition.
• [3s]: 3 seconds transition.
• [5s]: 5 seconds transition.
• [custom]: Allows selecting a duration from 0.5 second up to 25 seconds by 0.5 second step.
6-x-9 [PIP]: Allows to display a picture into another picture. The PREVIEW image is reduced and displayed
onto the MAIN image.
Select the [duration] of the transition, and validate with ENTER.
• [holding]: The PREVIEW image appears after pushing on the TAKE button, and will be removed
only by a second push on the TAKE button.
• [3s]: 3 seconds transition.
• [5s]: 5 seconds transition.
• [custom]: Select a duration from 0.5 second up to 25 seconds by 0.5 second steps.
Adjust the [size] of the PIP (between 15 and 100%) with H and V, and validate with ENTER.
NOTE: You can display the PIP source in is native resolution: set the horizontal & vertical size on 1:1.
Set the horizontal and vertical [position] of the PIP windows with the H and V knobs, and validate with
ENTER.
Adjust the [mask size] with the H and V knobs, and validate with ENTER. This function allows, for
example, cutting the black bars of a letterbox source.
Adjust the [mask position] with the H and V knobs, and validate with ENTER.
Select a type of [border] between "without", "shadow", "smooth", and "edge".
NOTE: The opening & closing animations available with this effect are: CUT, FADE, Horizontal &
Vertical slides, Horizontal & Vertical wipes.
6-x-10 [double PIP]: Allows to display the MAIN & PREVIEW sources as 2 PIP onto/under a background image
(frame).
Select the [duration] of the transition, and validate with ENTER.
Select a [background frame] and validate or not the [inlay].
For each MAIN & PREVIEW sources, adjust the [size], [position], [mask size] & [mask position].
As required, adjust the Prev. opacity (This function allows to insert title in the main PIP, see Figure 27:
Titling a PIP.).
NOTE: You can display the PIP sources in their native resolution: set the horizontal & vertical size on 1:1.
NOTE: The opening & closing animation available with this effect is: FADE.
