8
Appliance and Cabinet Cutout Dimensions
It is good practice, when an oven is installed at the end
of a cabinet run, adjacent to a perpendicular wall, or
cabinet door, to allow at least 1/4” (6.4 mm) space
between the side of the oven and the wall/door.
For oven support, install 2x4s extending front to back
flush with the bottom and the sides of the opening. The
supporting base must be well secured to the floor/
cabinet and level.
Junction boxes can be located anywhere within reach of
the oven’s power cable.
The cabinet base must be flat and capable of supporting
the weight of the combination oven up to 429 lbs.
(195 kg).
Dimensions for Single Oven Units
The cabinet base must be flat and capable of supporting
a weight of at least 232 lbs (105 kg).
Under oven dimensions are provided as a general
guideline and may be adjusted as needed based on a
particular application. Consult a design professional for
optimizing personal preferences.
Single Oven Appliance Dimensions
Single Oven Wall Mount Installation
*For single ovens installed into a wall cabinet, the
junction box may be located above, beneath, left or right
of the unit within reach of the power cord.
**For oven installation in a wall cabinet, the control panel
overlap is a minimum 3 /
8
" (10mm) to max. 2" (51mm).
Single Oven Flush Mount Installation
Flush installation requires two side cleats to be attached
inside the cabinet frame, recessed from the front.
Top View
Side View
PP
PP
ʌ¼ʚ
PLQë
PD[
ò
IOXVKLQVHW
GHSWK
т
ф
UHYHDO
FOHDWV
ô
UHYHDO
FOHDWV
PP
ò
ǫ
ǩ
IOXVK
FXWRXW
KHLJKW
PP
UHYHDO
FOHDWV
