7
Removing Packaging
Built-in Ovens:
1. Cut the straps.
2. Open top of carton and remove top wood frame.
3. Lift the carton up and over the appliance to remove, or
carefully cut along the cut line on the back left side of
the carton with a blade shorter than 3/4” and remove
carton.
4. Carefully remove internal protective packaging taking
care to secure any loose accessories and instruction
manuals.
5. Remove bracket(s) securing appliance to base pad, if
present.
6. The unit should stay on the packaging base until ready
to be lifted into cabinet cutout.
7. Install the appliance according to the installation
instructions.
Combination Ovens:
1. Cut the straps and remove angle board/strap
protectors from top of carton.
2. Open top of carton.
3. Lift the carton up and over the appliance to remove, or
carefully cut along the cut line on the back left side of
the carton with a blade shorter than 3/4” and remove
carton.
4. Carefully remove the microwave or steam oven carton
from top of bottom carton and place on floor.
5. Follow instructions on interior cartons for removal of
remaining packaging.
Packaging Bracket Removal-Left and
Right Sides
Note: Actual bracket varies in appearance. The bracket
remains in the packaging base. The unit should stay on
the packaging base until ready to be lifted into cabinet
cutout or onto the lower oven.
Preparing Ovens
Place ovens in front of the cabinet where it is to be
installed so that they are in line with the cabinet cutout.
Check to be sure all packing materials have been
removed from the unit. Also remove the accessories,
oven racks, literature pack and any shipping materials
from inside the oven cavity. Check both ovens for a
double oven or combination oven installation.
