6

Bosch Combination Ovens

The

HBL8743UC

,

HBL8753UC

and

HBL87M53UC

Bosch

combination ovens are sold as sets, each of which

includes two built-in oven components: a conventional

wall oven (lower oven) and either a built-in speed oven or

a microwave oven(upper oven).

For ease of installation and improved alignment, the

oven components are assembled together in the

customer’s home rather than at the factory.

Each of the components are packed in separate

boxes, which are strapped together prior to shipping.

The combination ovens listed here are approved for

use in a single cutout, using single power connection.

Each conventional oven component is designed with

an oven-mounted junction box on top, which is used

for connecting the upper oven power cable.

The hardware required for mounting the speed oven

on top of the conventional oven will be found inside

the conventional oven box.

Each of the oven components has its own rating label,

the component model number, FD number, etc.

Before you Begin

Tools and Parts Needed

Phillips-head screwdriver

Star-head screwdriver (T20)

Measuring tape

Drill with bit (1/8”)

Gloves

Utility Knife

Parts Included

Phillips head screws (6).

Power Requirements and Grounding

The outlet must be properly grounded in accordance with

all applicable codes.

For Best Installation

The oven can be difficult for two people to handle during

installation. It is recommended that three or more people

be available to assist with lifting the unit into place.
Removal of the oven door (to reduce the unit weight and

to provide necessary gripping points) can be

cumbersome unless the detailed door removal

instructions are followed carefully. Do not attempt to

remove the speed oven door.
Please take time to read and follow the instructions

provided for an improved installation experience.

Checklist

Use this checklist to verify that you have completed each

step of the installation process. This can help you avoid

mistakes.

Before installing the oven, be sure to verify the cabinet

dimensions are correct and the required electrical

connections are present.

Refer to additional information in this manual

regarding Safety, Cabinet Dimensions, Removing

Packaging, Electrical Installation, Testing the

Installation and Customer Service.

Remove the lower oven door to reduce the unit weight

and to provide access to gripping points for lifting. See

“Remove Lower Oven Door Prior to Installation”

information.

Move the oven units into place in front of the cabinet

opening, leaving the bottom packaging on the units to

avoid damaging flooring.

Remove the Star-head screws (T-20 size using Star-

head screwdriver) holding the speed microwave oven

to the base of its carton.

Assemble the two units of the combination oven. See

“Pre-Assembly of the Combination Oven”.

Connect the power cable from the lower oven to the

junction box in the cabinet.

Remove the Star-head screws (T-20 size using Star-

head screwdriver) holding the lower oven to the base

of its carton.

Team-lift the unit directly into the cabinet cutout taking

care not to pinch fingers, scratch arms or hands.

Slide the unit all the way into place.

Fasten the unit to the cabinet opening with the screws

supplied using a Philips screwdriver.

Reinstall the oven door removed in Step 3 above.

Consult the complete installation instructions and

follow the remainder of the procedures listed,

including performing operation test.

INSTALLER- Leave the literature pack and the

accessories with the customer.
