F Stop (8) button
Press to stop CD playback.
G Play/pause (y/9) button
Press when the CD or a supported Bluetooth device
is stopped or paused to start playback.
Use this button to pause playback during playback.
H Open/close button (-)
Press to open and close the disc tray.
I Turntable cover
J VOLUME knob
Use to adjust the volume. Turn right to raise the vol-
ume and left to lower it.
K PHONES jack
When you use headphones, first reduce the volume
level to minimum. Then, insert the plug from your
headphones into the PHONES jack, and turn the
volume up gradually by turning the VOLUME knob.
o Do not turn the unit on and put it into standby
or connect and disconnect the headphones plug
while wearing headphones.
(Doing so could cause loud noise to be output
from the headphones.)
o When a plug is in the headphones jack, no sound
will be output from the speakers.
L Analog audio input jack (AUX 2 IN)
Use to input analog audio signals.
To connect the headphones jack of a portable
music player or similar device to the unit, use the
included stereo mini plug cable to connect it to the
front panel analog audio input jack (AUX 2 IN). In
this case, adjust the volume on the portable music
player. Be careful, however, because turning the
volume of the portable music player up too much
could cause distortion.
M Remote control signal receiver
Signals sent from the remote control are received
here. When using a remote, point it toward this
spot.
N Display
This shows the track number, time, FM/AM fre-
quency and other information.
O Disc tray
P Scroll/skip knob
(MULTI JOG/. //j k)
Use when tuning the radio to select stations (page
49).
Use this also to set the current time and the wakeup
timer (pages 25 and 52).
When listening to a CD, use to skip to the previous
or next track (page 33).
Q Right/left speakers
Place the speakers as desired.
