16
Connecting the speakers
Use the included speaker cables to connect the
included speakers to the main unit.
Right speaker Left speaker
While pressing the lever, insert the end of the cable
(where the wire is exposed). Release the lever to con-
nect the speaker cable. Connect the cable to both the
main unit and the speaker.
Connections (2)
Connect the end of the + speaker cable with the mark
into the red speaker terminal.
Connect the end of the transparent − speaker cable
into the black speaker terminal.
o Gently pull the cables to make sure they are con-
nected firmly.
o Confirm that only the exposed part of the wire is
inserted into the terminal and that the cable sheath
is not touching the terminal.
o A short could occur if the exposed core wire at the
tip of a speaker cable touches another cable or
terminal.
o Never let the speaker cables short.
o In order to avoid noise, do not bundle speaker cables
with power cords or other cables.
The included speakers have bass ports in their backs.
Place the speakers so that these ports are not blocked
by, for example, other objects or walls.
Bass port
Speaker terminals
