7 Squeeze the trigger completely and
push the supply guide back into position.
Snap the top cover closed.
8 To clean the printhead, grasp the sides
of the latch and pull up. 9 Lift the printhead out of the labeler.
10 Brush the surface of print bands in a
circular motion with a stiff-bristled,
non-metalic brush.
11 Return printhead to original position,
slide eye onto hook.
12 Push latch toward the printhead while
holding printhead in place. Make sure
printhead is securely mounted.
Hook Print Bands Eye Latch
Printhead
Pull
