Chapter 1 : INTRODUCTION
1-1. SUPPLIED EQUIPMENT
• 1 HD SCAN ™ (XTD920).
• 1 Set of 19" Brackets.
• 1 AC power supply cord.
• 1 VGA cable (HD15 male / HD15 male).
• 1 CD-ROM (Remote Control Software).
• 1 User's manual.
1-2. GENERAL INFORMATION
The HD SCAN ™ is a professional Computer to High-Definition TV Scan Converter, which allows to convert your
workstation, PC or MAC Graphic Images (Up to 1600x1280), into HDTV.
The HD SCAN ™ features REAL TIME conversion with sized Aspect Ratio and Zoom up to 200%. The HDTV comes
with dual HDSDI output, and Tri Levels sync HD components.
• An HDSDI Genlock is also provided for further mixing with an external HDTV keyer.
• High performance Multi-levels of Anti-Flickers and smoothing Filters to significantly overcome the Sharpness &
Flickers of the HDTV output, thanks to its state of the art full RGB 16 million colors High Speed Hardware DSP.
1-3. HD SCAN
™ REFERENCES
REFERENCES DESIGNATIONS
XTD920-HDDG HD SCAN ™ with HDSDI GENLOCK.
XTD920-HDAG HD SCAN ™ with HD analog GENLOCK.
