Chapter 9 : TECHNICAL SPECIFICATIONS (continued)
HD SCAN™
PAGE 16
• OTHERS SPECIFICATIONS
HDTV clock:
74.250 MHz at 50 Hz & 60 Hz.
74.175824 MHz at 59.94 Hz.
Tolerance:
± 30 ppm (internal rate).
Holding range:
± 80 ppm (genlock rate).
Jitter:
130 psec (0.2 UI; alignment).
NOTE: 1 UI = 667 psec à 1.5 Gbps.
• REMOTE PORT
Level:
RS-232.
Data Rate:
9600 bauds, 8 bits data, 1 bit stop, no parity bit, no flow control.
• ENVIRONMENTAL
Power Supply:
Internal CE / UL / CSA / IEC 950 (50W).
Input: 100VAC to 250VAC; 50-60Hz; I = 1A Max.
Storage temperature:
-25 °C to +85 °C (-13°F to + 185°F).
Operating temperature:
0°C to 50°C (32°F to +122°F).
Maximum ambient operating temperature: <40°C.
Hygrometry:
10% to 80% (without condensation).
Dimensions:
W 440 x D 300 x H 44 mm / 17.3” W x 11.8” D x 1.74” H.
W = 480mm / 19" with the rackmount kit.
Compatible with 19" Standard, height = 1 unit.
Weight:
3.3 kg / 7.3 Lbs.
