HD SCAN™
PAGE 13
Chapter 7 : THE GENLOCK FUNCTION
7-1. INTRODUCTION
The genlock function allows to synchronize many video equipment in order to mix images together (i.e.: to overlay
graphic image onto incoming video)
7-2. CONNECTION
7-3. ADJUSTMENTS
Adjust the horizontal phase between the sync generator and the HDTV output, has to be equivalent to 0. Make the
adjustment with the LCD menu # 1-2 (genlock H ph).
