HD SCAN™
PAGE 15
Chapter 9 : TECHNICAL SPECIFICATIONS
• COMPUTER INPUT
Line frequency: Up to 110 kHz.
Frame frequency: Up to 130 Hz.
Resolution: Up to 1600 x 1280.
Sync. types: RGBHV, RGB/S, RGsB (Sync On Green).
Levels: R, G, B = 3 x 0.7 Vp/p.
H & V Sync = TTL
Composite Sync = TTL and 0.3 V.
SOG (Sync On Green) = 0.3 V.
Impedance: R, G, B = 75 Ohms.
H = 75 Ohms or Hi-Z.
V = 75 Ohms.
• HD ANALOG GENLOCK (ACTIVE LOOPTHROUGH) - XTD920-HDAG version only.
Signal: HD analog BLACK (720p @ 59.94 or 60 Hz, 1080i @ 50, 59.94 or 60 Hz, 1035i @ 59.94 or 60 Hz).
Impedance: 75 Ohms.
• HD SDI GENLOCK (ACTIVE LOOPTHROUGH) - XTD920-HDDG version only.
Signal: HD SDI BLACK (720p @ 59.94 or 60 Hz, 1080i @ 50, 59.94 or 60 Hz, 1035i @ 59.94 or 60 Hz).
Impedance: 75 Ohms.
• HD ANALOG OUTPUT (R-Y, Y, B-Y)
Levels: Y = 1 Vp/p (0.7 V + sync.).
R-Y = 1 Vp/p (0.7 V + sync.).
B-Y = 1 Vp/p (0.7 V + sync.).
Sync.: Tri-levels: ±0.3V (positive/negative).
Bi-levels: 0.3V (negative)
Impedance: 75 Ohms.
• HD SDI OUTPUT
Data rate: 720p @ 59.94 or 60 Hz: 1.5 Gbps serial digital output conforming to SMPTE 296M.
1080i @ 59.94 or 50 or 60 Hz: 1.5 Gbps serial digital output conforming to SMPTE 274M.
1035i @ 59.94 Hz: 1.5 Gbps serial digital output conforming to BTA-S004B.
1035i @ 60 Hz: 1.5 Gbps serial digital output conforming to BTA- S001.
Impedance: 75 Ohms.
