6
Location Requirements
Selecting the proper location for your washer improves performance and minimizes noise and
possible washer “walk.”
Your washer can be installed under a custom counter, or in a basement, laundry room, closet,
or recessed area. See “Drain System.”
Companion appliance location requirements should also be considered. Proper installation is
your responsibility.
You will need
„ A water heater set to deliver 120°F (49°C) water to the washer.
„ A grounded electrical outlet located within 6 ft (1.8 m) of where the power cord is
attached to the back of the washer. See “Electrical Requirements.”
„ Hot and cold water faucets located within 4 ft (1.2 m) of the hot and cold water fill valves,
and water pressure of 20-100 psi (137.9-689.6 kPa).
„ A level floor with a maximum slope of 1" (25 mm) under entire washer. Installing the
washer on soft floor surfaces, such as carpets or surfaces with foam backing, is not
recommended.
„ A sturdy and solid floor to support the washer with a total weight (water and load) of
400 lbs (180 kg).
Do not operate your washer in temperatures below 32°F (0°C). Some water can remain in the
washer and can cause damage in low temperatures. See “Washer Care” for information on
winterizing.
Installation clearances
„ The location must be large enough to allow the washer door to be fully opened.
„ Additional spacing should be considered for ease of installation and servicing. The door
opens more than 90°, and it is not reversible.
„ Additional clearances might be required for wall, door, and floor moldings.
„ Additional spacing of 1" (25 mm) on all sides of the washer is recommended to reduce
noise transfer.
„ Companion appliance spacing should also be considered.
Washer Dimensions
27"
(686 mm) 50¼"
(1276 mm)
36"
(914 mm)
30½"
(775 mm)
Door is not reversible.
Recommended installation spacing for custom undercounter installation
The dimensions shown are for the recommended spacing.
Custom undercounter installation - Washer only
1"
(25 mm)
1"
(25 mm)
37" min.
(939 mm)
27"
(686 mm)
Recommended installation spacing for recessed or closet installation, with or without
a pedestal
The dimensions shown are for the recommended spacing.
