Maytag MHWZ600WR - Manuel (Page 11)

11
„ Check the temperature of the water to make sure that the hot water hose is connected to
the hot water faucet and that the cold water hose is connected to the cold water faucet.
Connect the inlet hoses to the washer
IMPORTANT: Make sure that the flat washers have been placed into the hose couplings.
C H
C. Cold water inlet
H. Hot water inlet
1. Attach the hot water hose to the washer’s hot (H) water inlet valve. Screw on coupling by
hand until it is seated on the washer.
2. Attach the cold water hose to the washer’s cold (C) water faucet. Screw on coupling by
hand until it is seated on the washer.
3. Using pliers, tighten the couplings with an additional two-thirds turn.
NOTE: Do not overtighten. Damage to the coupling can result.
4. Turn on the water faucets completely and check for leaks.
NOTE: Replace inlet hoses after 5 years of use to reduce the risk of hose failure. Record
hose installation or replacement dates on the hoses for future reference.
Periodically inspect and replace hoses if bulges, kinks, cuts, wear, or leaks are found.
Connect the Drain Hose
Remove drain hose from washer drum
1. Use locking pliers, squeeze hose clamp tabs together and insert over the end of drain
hose.
2. Slide drain hose onto washer connection.
