Monogram 36 Inch Freestanding Professional Induction Smart Range Installation Instructions - Manuel (Page 9)

31-2001170 Rev 0
9
Installation
2
MOVE THE RANGE INDOORS
1. Tilt the range forward on the skid.
2. Lift the toekick out of the foam base.
3. Drive the blade of the hand-truck beneath the foam
block.
The hand-truck can be installed on either the right or
left side of the range, but cannot be installed on the
front or rear of the range.
IMPORTANT: Do not remove the base foam block while
the hand-truck is in use. Place the hand-truck blade
underneath the base foam block and transport the range
to the final location.
4. Attach the hand-truck straps around the unit.
IMPORTANT: Place the hand-truck straps below the
oven door handles. To avoid damaging the side panels,
place a pad between the hand-truck and the range.
5. Tilt the range to lower the hand-truck wheels off the
skid.
6. Move the range indoors. Position the range in front of
the installation location.
Toekick
Toekick
Insert Blade Under
the Foam Block
Hand-Truck
Straps Below
Oven Door
Handles
Range
Opening
